Ozone + UV Dual Sterilization · Continuous Closed-Loop Supply

Central Medical Purified
Water Treatment Systems

Multi-stage reverse osmosis (RO), EDI electro-deionization, and continuous chemical-free bacterial inhibition designed for multi-chair dental operatory pipelines, autoclaves, endoscopy centers, and hospital CSSD sterile reprocessing.

Desalination Rate ≥ 99.7% Efficiency
Water Conductivity ≤ 1.0 μS/cm (or EDI)
Bacterial Inhibition Ozone + UV Dual Unit
Explore Models & Specs 6-Stage Process Topology
Hongrun Purified Water Treatment Station (Full Machine)
Full View
HRC Series Integrated Machine Medical Pure Water
HRC System Family

Standard & Heavy-Duty Clinical Water Units

Equipped with Dow/Toray RO membranes, SUS316L sanitary pipelines, automatic chemical-free ozone backwash, and online conductivity/TDS continuous monitoring.

HRC-60 Dental Water Station

HRC-60

1–3 Chairs

Compact clinic station for dental chair handpiece water & benchtop autoclave supply.

  • Output: 60 L/h (25°C)
  • Desalination: ≥ 98.5%
  • Sterilization: UV In-line Sterilizer
  • Conductivity: ≤ 5 μS/cm
Get Custom Proposal
HRC-100S Central Dental Purifier

HRC-100S

4–8 Chairs

Integrated cabinet design with dual Ozone + UV bactericidal circuit & 80L pressurized storage.

  • Output: 100 L/h
  • Desalination: ≥ 99.0%
  • Sterilization: Ozone generator + UV
  • Storage: 80L Aseptic Tank
Get Custom Proposal
HRC-300 Large Clinic & Hospital CSSD System

HRC-300

10–20 Chairs / CSSD

Dual-pass RO skid with constant pressure variable-frequency loop circulation for multi-floor dental clinics.

  • Output: 300 L/h
  • Loop Control: Constant Pressure VFD
  • Microbial Count: < 10 CFU/100ml
  • Piping: Sanitary SUS304/316L
Get Custom Proposal
HRC-1000 Hospital Central Water Purification Skid

HRC-1000 / 2000

Hospital Central

Industrial medical-grade multi-stage double RO + EDI unit for sterile reprocessing & centralized clinical wings.

  • Output: 1000 – 2000 L/h
  • Resistivity: Up to 10–15 MΩ·cm
  • PLC Automation: Siemens PLC + 10" HMI
  • Redundancy: Dual Booster Pumps
Get Custom Proposal

HRC Technical Specification Matrix

Comprehensive parameters across standard clinic and centralized hospital installations.

CE & ISO 13485 Compliant
Model Water Output (25°C) Inlet Pressure Power Rating Desalination Rate Conductivity (Output) Clinical Application
HRC-60 60 L/h 0.15 – 0.40 MPa 0.37 kW / 220V ≥ 98.0% ≤ 5 μS/cm 1–3 Dental Chairs
HRC-100S 100 L/h 0.20 – 0.45 MPa 0.75 kW / 220V ≥ 99.0% ≤ 3 μS/cm 4–8 Dental Chairs + Autoclaves
HRC-300 300 L/h 0.20 – 0.50 MPa 1.50 kW / 220V/380V ≥ 99.2% ≤ 2 μS/cm 10–20 Chairs / Endoscopy Clean
HRC-500 500 L/h 0.25 – 0.50 MPa 2.20 kW / 380V ≥ 99.5% ≤ 1.5 μS/cm Large Stomatology Hospital / CSSD
HRC-1000 1000 L/h 0.25 – 0.55 MPa 4.00 kW / 380V ≥ 99.7% (2-Stage RO) ≤ 1.0 μS/cm (or EDI ≥10MΩ) Hospital Sterile Reprocessing Center
Multi-Stage Purification Topology

6-Barrier Clinical Water Safety System

From raw municipal tap water to clinical ultrapure standard, preventing biofilm growth in dental chair waterlines (DUWL) and hospital piping.

01

Sand / Quartz

Removes suspended solids, rust, and particulates > 20μm.

02

Active Carbon

Adsorbs residual chlorine, organic matter, odors, and VOCs.

03

Ion Softener

Eliminates Ca²⁺/Mg²⁺ ions to protect RO membranes from scaling.

04

RO Membranes

0.0001μm filtration removing >99% heavy metals, bacteria, viruses.

05

Ozone Gen

Constant background dissolved O₃ destroying microbial biofilms.

06

UV-C 254nm

Terminal germicidal irradiation before feeding clinical chairs.
